6mm Hydraulic Guillotine Shearing Machines

6mm Hydraulic Guillotine Shearing Machines Yawei manufactures in china 8FT Variable Rake angle metal sheet guillotine shearing machines suppliers china 6mm hydraulic metal guillotine cutting machines for sale china Anhui Yawei 6mm*2500mm Hydraulic Metal Sheet cutting machines made in china █...

6mm Hydraulic Guillotine Shearing Machines Yawei manufactures in china

8FT Variable Rake angle metal sheet guillotine shearing machines suppliers china

6mm hydraulic metal guillotine cutting machines for sale china

Anhui Yawei 6mm*2500mm Hydraulic Metal Sheet cutting machines made in china

█ General Features of 6mm Hydraulic Guillotine Shearing Machines:

Full welded structure machined on CNC Boring&Milling machine

Construction feature have a variable rake cutting angle, hydraulic metal guillotine cutting design

Machine body and top beam are made of steel constructions, has been designed according minimum stretch and optimum resistance

Swing up back gauge design for Anhui Yawei Hydraulic guillotine shears for sale china

2 Units down stroke Hydraulic Cylinders, processed as precise from solid full material and made honed

Pistons, processed from forged steel, hardened,grinding is done

Welded Monoblock, heavy steel frame using rigid structural steel produced with advanced modern fabricating methods.

Cutting stroke adjustable

• Used in Carbon Steel, Mild and Stainless Steel Cutting, Aluminum sheet plate cutting.

Standard Equipment of Anhui Yawei 6mm*2500mm Hydraulic Metal Sheet guillotine cutting machines:

• ESTUN E21 NC Controller, can program and go to position function

• Taiwan Shilin Frequency inverter

Cutting angle adjustable, manual adjust cutting angle according to different plate thickness

• Cutting stroke adjustable, when cutting short parts, stroke reduced, speed increased

• Cutting times count with read-out

Return by nitrogen gas

Siemens electric components

Three standard front support

Automatic, digital controlled Motorized back gauge with ball shaft and guiding

Easily adjustable with blades gap setting for precise cutting and longer using life

Roller bearings on working table to feed sheets to the cutting blades easily

Hydraulic sheet hold down system, holds the sheet in place during cutting process

Simple and easy blades gap adjusting device

4 cutting edges of hydraulic metal cutting blades suppliers made in china

China top level compact hydraulic system

Rear safety fence and front finger protection guards

Standard rear plate slipper

Removable foot pedal with Emergency stop buttons

8FT Variable Rake angle metal sheet guillotine shearing machines specifications

Max metal cutting thickness6mmMax metal cutting length2500mm
Variable rake angle0.5-1.5 degreeThroat depth800mm
Back gauge stroke600mmMain motor power7.5kw
Gross weight5.0TDimension3000*1700*2000mm



 Main parts of Anhui Yawei QC11K-6*2500 Hydraulic Guillotine Shearing Machine

Manual adjusting for metal cutting blades clearance

3 Units front support with rules, metal guillotine cutting machines made in china

2 Units main hydraulic cylinders, NC motorised metal cutting machines

Cabinet of 6mm Hydraulic Guillotine Shearing Machines Yawei manufactures

ESTUN E21S NC Hydraulic guillotine shears controller, Taiwan brand frequency inverter

NC Motorised back gauge



Delivery time: within 25 days after we get 30% down payment in advance

Shipping terms: 1*20GP container

Payment terms:30% down payment in advance and balance before shipment
