QC11K CNC Guillotine Shear 16×6100

QC11K-16×6100 █ General Features: • Full welded structure machined on CNC Boring&Milling machine • Construction feature have a variable rake cutting angle • Machine body and top beam are made of steel constructions, has been designed according minimum stretch and optimum resistance • Heavy...

QC11K-16×6100

General Features:

• Full welded structure machined on CNC Boring&Milling machine

• Construction feature have a variable rake cutting angle

• Machine body and top beam are made of steel constructions, has been designed according minimum stretch and optimum resistance

• Heavy duty 6m cutting capacity design

• Swing up back gauge design

•2 Units down stroke Hydraulic Cylinders, processed as precise from solid full material and made honed

• Pistons, processed from forged steel, hardened,grinding is done

• Welded Monoblock, heavy steel frame using rigid structural steel produced with advanced modern fabricating methods.

• Large 6m Hydraulic Sheet Cutting Machines

• Cutting stroke adjustable

Standard Equipment:

• ESTUN E21 NC Controller, can program and go to position function

• Frequency inverter

• Cutting angle adjustable, manual adjust cutting angle according to different plate thickness

• Motorized NC blades clearance adjustment

• Siemens electric components

• Five units standard front support

• Fast and powerful back gauge with 1000mm cutting stroke

• Back gauge lifting system to ensure you cut longer plate than back gauge stroke

• Bigger throat 350mm, which can ensure you cut longer plate than 6.1m

• Heavy rollers on cutting table to hold heavy cutting plate

• Top blade 4 cutting edges, bottom blade 4 cutting edges

• China top level compact hydraulic system

• Removable foot pedal with Emergency stop buttons

Optional Equipment:

• Yaskawa Servo motor and drive controlled

• DELEM DAC360, CYBELEC TOUCH 6 CNC controller

• CNC Controlled automatic cutting angle,cutting length, cutting stroke and back gauge

• Ball screw and linear guide back gauge

• Pneumatic sheet support system

• CE Front&Rear light guard

• Special throat 500mm

Technical Specifications:

QC11K CNC Guillotine Shear 16×6100

Max.Cutting thickness

16mm M.S

Cutting Length

6100mm

Variable Cutting Angle

0.5-3.0 degree

X Back gauge Stroke

100mm

Stroke Times

5/min

Throat depth

350mm

Main motor power

37kw

Gross Weight

30.0T

Dimensions(L*W*H)

7000*2500*3200mm

• Delivery time: Within 40 days

• Payment term: T/T, 30% down payment in advance and balance before shipment

• Warranty: 18 months

• Loading port: Shanghai, China

• Certificate: ISO, special requirements for CE conformity

• After Sales Service: 7*24 hours, quick response

• Shipment: one 40 ft Flat Rack container

• Installation Service and Training Service are all available if required

• Customer’s profile testing before shipment
