This China Ahyawei AHYW Hybrid CNC Press Brake-3m100T is Hydrid metal bending machines, which adopts ESTUN servo motor to drive pump, the pump only start working only when pressbrake operator press footpedal with metal bending procedure, it will just standby when no workpiece bending, which will save electricity and oil consumption, it's one elvolutionary synchro cnc press brakes
█ Advantages of China Yawei AHYW 100Ton3m DA66T Hydrid CNC Press Brakes 4 Axis
• The Fastest: 18-20 mm/sec bending speed, approach can reach 220mm/s, return speed 200mm/s.
• It is a fast operating press brake using servo motors and highly efficient pump.
Eco – Friendly
• The new series press brakes are eco-friendly using comparably less energy than a standard press brake.
• An average 40% energy saving when used in comparison to standard press brakes.
• Reduced oil level: 30%
• Bending efficiency
Highest bending efficiency is achieved as no pressure is lost through proportional valves.
• Quietest in its class: 63db
• 3x longer system life time
System and pump have 3 times longer lifespan due to high quality components and smart running technology.
• Oil does not heat up
Oil is more durable than ever because the oil does not heat up , as the pumping system which does not run when the machine is at stand-by mode.
There is almost no any oil running when press brake ram downing
Technical Paremeters of Yawei AHYW Hydrid CNC Press Brakes 100Ton3m
| Max bending pressure | 100Ton | Max metal bending length | 3200mm, 10FT |
| Side frames distance | 2700mm | Max daylight | 420mm |
| X bending back gauge | 600mm | R axis bending back gauge | 150mm |
| X moving speed | 400mm/s | Approach speed | 220mm/s |
| Main servo motor power | 6kw | Bending speed | 18-20mm/s |
| Gross weight | 7.5T | Dimension | 3600*1900*2400mm |
Main images of Yawei AHYW 100Ton3m DA66T Hydrid CNC Press Brakes 4 Axis manufactures, suppliers in china
Tha
Main servo motor to drive pump for China AHYW Yawei Hybrid CNC Press Brakes manufactures
DA66T Touch screen 2D cnc press brakes controller
2 pcs finger stops moved on dual linear guide for Synchro Hybrid CNC press brakes China Yawei manufactures factory
German Heidenhain Linear scale for China Ahyawei CNC press brakes manufactures
Jpan Yaskawa servo motor and drive for 2 axis cnc controlled press brake back gauge
Ball screw&linear guide cnc automatical press brake back gauge factory forsale made in China
AHYW Yawei China have more options for Hybrid Pressbrakes 4 axis for 4m metal bending with Hoerbiger Eprax Hybrid system
AHYW Yawei PBM Main Electro Hydraulic structure of Hybrid Press Brake Machines:
AHYW Hoerbiger ePrAX hybrid system mounted directly on top of Y1&Y2 cylinders;
valves, pump,servo drive and oil tank are compactly integrated in the ePrAX.
Customer’s Benefit Of Hybrid ePrAX 3M&4M PBM CNC Hybrid Press brakes:
1, Reduced cycle time at same speeds
Press brake ram approach -mute-bending-decompression-return , Hybrid press brake machine can save up to 30% cycle time
2, Eco-friendly
When you are considering purchase a hybrid press brake, the first thing to look at is energy savings.
Using Hybrid servo brakes press 3Mtr/125T as an example, customer can get a 62% energy savings while in standby mode, 44% savings during the press cycle and 60% savings over one hour. 3,Quietest
One thing that we love Hybrid press brake machine is that when it’s in standby mode and not moving when handling bending material, it’s running silently, fully noiseless
4,Ease of application&maintenance
Y1&Y2 have independent oil tank, all hydraulic components are integrated in Hybrid system, no need hydraulic expertise
5, Less of oil consumption
Oil capacity at 34.5L*2 units, no need to change oil within 7000 working hours
6, Less of electricity consumption
Servo variable speed motor-pump won’t running if operator do not press pedal
7,Accurate
Servo Hybrid press brakes are much more accurate than standard hydraulic pressbrake machine. Each side of a hybrid press brake is independently operated by its own hydraulic system, with each cylinder having its own servo motor and valve controlling it. Beyond the accuracy of the scale hybrid press brakes have each servo motor measuring and controlling the amount of fluid that we’re pushing through the valves. So it’s more controlled, on command, like a direct drive system. It’s very fast and very accurate.
8, Oil don’t heat up
9, Higher Bending efficiency
Highest bending efficiency is achieved as no pressure is lost without proportional valves.
